Each model of the infant restraint comes with different harness

options. To adjust your infant restraint properly, it is very

important to follow the instructions that are appropriate for the

model you have purchased.

2.0 Features and Components

5-Point Harness3-Point Harness

Base

Vehicle belt

path

Boot

(on certain models)
